1. Coolant compressor
Adopting Japanese brand Panasonic, Hitachi, Daikin and other digital rotor or scroll compressor brings ultra-high energy efficiency, outstanding reliability and less moving parts. The patented flexible design provides unprecedented resistance to liquid and tolerance;
Configure the motor overheat protection device to protect the motor from high temperature and high voltage flow;
Low noise and low exhaust pulse noise value is 5 decibels lower than piston compressor;
2. Evaporator/heat exchanger
Adopt high efficiency heat exchanging copper tube to enlarge the heat exchange area over 10%. Thus the heat exchange efficiency increase 30% compared with traditional model.
3. Water Condenser
The main function of the condenser is to cool the high temperature and high pressure refrigerant air discharged from the refrigeration compressor into a high pressure liquid and transfer the heat to the cooling medium. The condensation process can usually be divided into three stages: 1 releasing the superheated heat of the refrigerant superheated steam until it reaches the condensation temperature and becomes saturated steam, which is called the cooling phase; 2 when the condensation temperature remains constant, it is released. The heat is condensed to make the saturated steam into a saturated liquid. This stage is called the condensation stage. 3 A part of the liquid is cooled to make the saturated liquid become a super-cooled liquid. This stage is called the super-cooling stage. The dominant part of the overall heat load of the condenser is the heat of condensation.
4. Pressure control switch
The pressure controller is used to protect the compressor from excessive suction pressure or excessive exhaust pressure. It is made by a professional manufacturer. It is small in size and easy to install. It has reliable action and good sensitivity. It can ensure rapid action when the pressure of the refrigerant is too high. It has better anti-vibration and anti-shock settings to ensure stable operation of the refrigeration system and improve product stability.
5. Heat expansion valve
The expansion valve is a throttling device that regulates the flow of liquid refrigerant flowing into the evaporator depending on the thermal load of the evaporator. The main function of the valve is to maintain the maximum cooling capacity of the evaporator and prevent liquid refrigerant from entering the compressor through the suction line to protect the compressor.
6. Patented water drainage device
Simple and ingenious integrated suction and sewage design, with large capacity condensate storage space and deposition depth, standard manual ball valve and electronic drain valve, which can reliably and thoroughly remove condensate water.
7. Auto drain valve
The function of the electronic drain valve is to remove the condensate water from the air compressor, cooler, water separator, refrigerated dryer and air filter in a timely manner. The condensate water discharge time is adjustable from 0.5 minutes to 45 minutes, and the discharge time is adjustable from 0.5 seconds to 10 seconds. Specially equipped with a transparent flame-retardant waterproof cover to ensure that the drain valve coil is not easily damaged.
8. Power switch, contactor and thermal relay
Careful selected long-life and high-sensitively switches, contactors and thermal relays, which can quickly jump off when the machine is overloaded to avoid the delay of the machine. All have pass the CE/UL certification.
9. Dry filter
The dry&filter combination design can effectively prevent moisture, filtrate and soluble matter from entering key parts of the refrigeration system, thus ensures that the system operates under optimal conditions.
