The working principle of heatless regenerative desiccant air dryer is taking the theory of Pressure Change Adsorption. The desiccant absorbs moisture of compressed air under the pipe network's pressure, then adsorption under the atmosphere pressure. Retrieving some dry air from the outlet of dryer to dehydrate the desiccant, adsorption in one tank and desorption in the other tank, two tanks work alternately and re-cycle, so the clean and dry compressed air will be supplied continually.
1. Stable pressure dew point
Reasonable cylinder design can longer the contact time between compressed air and desiccant, slow the air flow, achieve high adsorption efficiency, and stable the initial pressure.
2. Long service life
An additional 30% desiccant proportion is used to compensate for the natural aging of the desiccant to ensure dry quality. The incoming compressed air is filtered by high efficiency oil remover to keep the desiccant from contamination. Under normal conditions, desiccant service life is more than 3 years.
3. Flexible customized requirement
Pressure: standard pressure, medium pressure, high pressure
Capability:0.8-500m3/min
Pressure dew point:-12°~ -70°
Two tower switching cycle:4min ~ 8hours
Adsorbent:Activated alumina and molecular sieve
Control system:PLC
Power supply:220V/1PH/50Hz-380V/3PH/50Hz, etc.
Any special customizes requirements are welcome
