1. Energy saving
The compressed heat regeneration technology is used to consume partial of the hot compressed air from the centrifugal air compressor to regenerate the adsorbent, thereby achieving the best energy saving effect.
2. High reliability
Referring to international advanced design concepts, designs and technical details, simultaneously, adopting high reliability valves and control systems to ensure system reliability.
3. Armoured double tower structure ensures continuous work
The dryer can continuously output clean, dry air. The adsorption tank shall be designed, manufactured, inspected and accepted according to GB150 "Steel Pressure Vessel" and the "Guidelines for Safety Supervision of Pressure Vessels" issued by the State Bureau of Quality and Technical Supervision. Submit a full set of compliant pressure vessel files
4. Configured with high efficiency air water separation filter
The dryer is equipped with a high-efficiency air-liquid separator and filter to effectively purify and separate free liquid (solid) particles. It can effectively protect the adsorbent from being impacted and contaminated by liquid water and prolong the service life of the adsorbent.
5. Configured with high efficiency post dust filter
A dust filter is placed at the dryer outlet. It can effectively remove the secondary pollution caused by the detachment of the adsorbent powder during the drying process. In addition, the inlet and outlet of the drying tower housing are provided with a ducted filter, which can filter and separate particles and evenly distribute the airflow.
6. Intuitive control of pressure temperature
A pressure gauge and a temperature gauge are arranged on the tower housing to visually display working conditions such as working pressure and regeneration temperature. The upper and lower heads of the casing are provided with a feeding port and a discharge opening for convenient replacement of the adsorbent.
7. Stainless steel air distributor
Apureda's unique technology uses 316L stainless steel to make an air distributor, which allows compressed air to enter the adsorption tower evenly. Therefore, fully absorbs and regenerates compressed air and adsorbent materials. At the same time, the speciality of stainless steel can resist erosion from high temperature, high speed, high pressure and fully saturated humid gas. Thus, eliminates the major safety hazard caused by the adsorbent entering the following pipelines upon inferior air distributor bursting due to corrosion.
No maintenance under usual operation.
8. Intelligent control and adjustment
PLC automatic control systems ensures the parameters be transmitted to the upper monitoring computer effectively.
1. Energy saving
The compressed heat regeneration technology is used to consume partial of the hot compressed air from the centrifugal air compressor to regenerate the adsorbent, thereby achieving the best energy saving effect.
2. High reliability
Referring to international advanced design concepts, designs and technical details, simultaneously, adopting high reliability valves and control systems to ensure system reliability.
3. Armoured double tower structure ensures continuous work
The dryer can continuously output clean, dry air. The adsorption tank shall be designed, manufactured, inspected and accepted according to GB150 "Steel Pressure Vessel" and the "Guidelines for Safety Supervision of Pressure Vessels" issued by the State Bureau of Quality and Technical Supervision. Submit a full set of compliant pressure vessel files
4. Configured with high efficiency air water separation filter
The dryer is equipped with a high-efficiency air-liquid separator and filter to effectively purify and separate free liquid (solid) particles. It can effectively protect the adsorbent from being impacted and contaminated by liquid water and prolong the service life of the adsorbent.
5. Configured with high efficiency post dust filter
A dust filter is placed at the dryer outlet. It can effectively remove the secondary pollution caused by the detachment of the adsorbent powder during the drying process. In addition, the inlet and outlet of the drying tower housing are provided with a ducted filter, which can filter and separate particles and evenly distribute the airflow.
6. Intuitive control of pressure temperature
A pressure gauge and a temperature gauge are arranged on the tower housing to visually display working conditions such as working pressure and regeneration temperature. The upper and lower heads of the casing are provided with a feeding port and a discharge opening for convenient replacement of the adsorbent.
7. Stainless steel air distributor
Apureda's unique technology uses 316L stainless steel to make an air distributor, which allows compressed air to enter the adsorption tower evenly. Therefore, fully absorbs and regenerates compressed air and adsorbent materials. At the same time, the speciality of stainless steel can resist erosion from high temperature, high speed, high pressure and fully saturated humid gas. Thus, eliminates the major safety hazard caused by the adsorbent entering the following pipelines upon inferior air distributor bursting due to corrosion.
No maintenance under usual operation.
8. Intelligent control and adjustment
PLC automatic control systems ensures the parameters be transmitted to the upper monitoring computer effectively.
